Product Description:
The surface-treated special PI film is used as the substrate, coated with a layer of high-temperature-resistant organosilicon pressure-sensitive adhesive on one side, and dried to form a stable surface protection film for high-temperature processes. The film is coated on one side with a layer of high temperature resistant silicone pressure sensitive adhesive and dried to form a stable surface protection film for high temperature process.
Product structure：
Film Color: Brown
Substrate material: PI film
Total thickness:0.070mm
Gel: Silicone Pressure Sensitive Adhesive
Length:33m
Performance Parameters:
Item | Specification | Test Method |
Total thickness | 0.070±0.003mm | GB/T 7125-1999 |
Substrate thickness | 0.025±0.001 mm | GB/T 7125-1999 |
Adhesion | ≥500g/25 mm | GB/T 2792-1998 |
Initial Tackiness | ≥20# | GB/T 4852-2002 |
Heat Resistance | No residue, no buckling | Stick 304 stainless steel plate, bake in 260℃ oven for 60 minutes and then peel off. |
Product Characteristics:
●High adhesion, moderate initial adhesion;
● Excellent high temperature resistance;
● Good adhesion stability, no residual adhesive on peeling.
Applications:
Used as a protective film in high temperature environments.
Storage conditions:
Prohibit transport or storage with volatile organic solvents, avoid direct sunlight and rain.
Optimum storage conditions: temperature 23±2℃, relative humidity 50±5%RH.
Use within 6 months of production date for optimal use performance.
Cautions:
The above technical data is for reference only.
When using this product, please conduct a thorough test of suitability for the purpose (object to be protected, conditions of use, etc.) beforehand.
Different adhesive objects and different laminating conditions may cause abnormalities such as peeling and residual adhesive.
